Flap Gate - Hikvision

The DS-K3Y220X

series swing barrier with 4 pairs of IR lights is designed to detect unauthorized entrance or exit. By adopting the flap barrier integratedly with the access control system, person should authenticate to pass through the lane via presenting IC or ID card, scanning QR code, etc. It is widely used in factories, construction sites, residences, etc.

> 4 pairs of IR light detectors: Permissions validation and anti- ailgating.
> LED light indicates passing direction.
> Valid passing duration settings: System will cancel the passing permission if a person does not pass through the lane within the valid passing duration.
> Door remaining open when fire alarm triggered: The door wings will be free status.
> Built-in access control board and card readers.
> Support speaker and remote control keyfob optional, need to order separately.
