Swing Turnstile - Tiso

Key advantages

• BMDrive® - Reliable mechanism with powerful BLDC gear motor ensures long term maintenance free operation
• High speed of leaf opening / closing within 0.3-0.6 sec provides high flow rate;
• The safety function of locking system BMDrive® prevents the glass leaf breaking in case of vandalism, and also automatically restores the full operation of turnstile after excessive loads on the leaf;
• Fast and durable leaf locking system ToothLock® works in two modes HiSecurity and LowNoise;
• LowNoise mode makes the turnstile operation almost silent
• The smart self-diagnosing system of mechanism BMDrive® automatically analyzes the system, detects critical malfunctions, and records error log and warnings;
• The BMDrive® mechanism controller is equipped with an OLED display for easy setup and configuration without special programmers, also a full configuration and diagnostics is possible via a USB connector by using a service software for Windows OS;
• Digital control of force and leaf speed in combination with six safety sensors prevent a passing person from being struck by a leaf, even in case of an unauthorized passage;
• By use of artificial intelligence algorithms and large number of high-precision infrared passage sensors, the Sweeper-BM turnstile detects and sounds the alarm when two people try to pass by one card, pass in the wrong direction and pass without authorization;
• Sensor system allows detecting the passage of person with luggage, arranging a free exit without the need for identification;
• Elegant cabinets equipped with integrated LED lighting
- DotLights® LED lighting display showing access status
- RFIDLights® - LED Light of card reader area
- EdgeLights® - LED Light of glass partitions showing turnstile access status;
• Wide passage solution for disabled and trolley access that can be combined with narrow passage;
• Safe and swing tempered glass leaves;
• Successful combination of affordable price and high quality;
• The ability to customize housing design and top lid;
• Low power consumption ;
• Can be integrated with any type of access control systems;
• Wired remote control panel in standard kit;
• In case of power failure, leaves could be opened manually (fail-safe);

Options

• Any access control systems upon request (e.g. RFID / Proximity / BioMetric readers, coin acceptor, push button, barcode and QR-code reader)
• passage counter
• Sound alarm
• MP3 audio module with micro SD card
• Ramped base mobile platform
